Intel
®
EP80579 Integrated Processor Product Line—Debug Port Design Guide
Intel
®
EP80579 Integrated Processor Product Line
Platform Design Guide May 2010
258 Order Number: 320068-005US
26.0 Debug Port Design Guide
26.1 Overview
This chapter provides information about the design of an eXtended Debug Port (XDP).
The details of this chapter are requirements for debug port design, unless the text
explicitly states that a design rule or connection is optional.
Note: The ITP-XDP and ITP-XDP2 are run-control tools created by Intel® Corporation. They
are not sold publicly by Intel. In this document, the term ITP and ITP-XDP can be
interchanged with “run-control tool.” Intel works with several run-control tool vendors
to create tools that can be used for design (the guidelines presented within this
document must also be followed). These vendors include:
• American Arium*
• International Test Technologies*
• Antron Electronics*
26.2 Terms and Definitions
Table 94. Terms and Definitions
Term Definition
BPM
Break Point Monitor - Processor pins used by run-control tools to monitor and
influence the internal state of the processor
Debug Port
Connection into a processor/chipset/platform environment used to provide
control during debug and validation.
EMTS Electrical Mechanical Thermal Specification
I
2
C Inter-IC Bus. A two-wire serial interface.
ITP
In-Target Probe. An ITP is a run-control tool as produced by Intel as well as
third party vendors. This specification is not meant to imply that any vendor’s
debug tool is preferred over any other. Contact your Intel representative for
alternative vendors supporting the XDP.
ITP-XDP A specific ITP for the eXtended Debug Port
ITP-XDP2
Functionally identical to ITP-XDP with the single added feature. of a built in
USB power assist module.
JTAG Joint Test Access Group. IEEE Standard 1149.1 style scan chain.
Local Tap Master
A device other than the ITP that is designed to control accesses into an IEEE
Standard 1149.1 style scan chain and all TAP agents contained within that scan
chain.
OCP Observation Control Port
Power Detection of and response to the system powergood state.
Reset Detection and control of reset state for elements within the system.
