Intel EP80579 Guide

Intel
®
EP80579 Integrated Processor Product Line May 2010
Order Number: 320068-005US 92
Platform System Clock—Intel
®
EP80579 Integrated Processor Product Line
The CK410 pins require the following stuffing options:
• The series resistor, designated as Rs (33 Ω), and parallel resistor, designated as Rt
(49.9 Ω), are required for CK410 output differential clock (Figure 53).
• The series resistor, designated as Rs (33 Ω) is required for CK410 output single-
ended clock (Figure 53).
Table 16. CK410 Clock Groups
Clock Group Name
Frequency
(MHz)
Receiver
Host_CLK 100/133 IA-32 core and ITP (Debug Port)
CLK100 100 PCI Express slot, PCI Express, SATA
CLK33 33 PCI Clock, LPC, Firmware Hub, Port80, TPM, SIO, and ITP Debug
CLK14 14.318 ICH
CLK48 48 USB
Table 17. Platform System Clock Reference
Clock Group CK410 Pin Component
Component Signal
Name
Host_CLK
CPU_0
IA-32 core 100/133 MHz Clock
CLKP100
CPU_0#
CLKN100
CPU_1
NC (No Connect)
CPU_1#
CPU_2
ITP - - ITP_BCLK
BCLKP
CPU_2#
BCLKN
CLK100 SRC
DB800 (SRC Differential Buffer) - PCI Express
Slot
SRC_IN(p/n)
PCI Express
PEA_REFCLK(p/n)
PCI Express x8 Slot
PCIE_x8_100_MHz_(p/n)
SATA
SATA_CLKREF(p/n)
CLK14 REF
EP80579 - ICH 14 MHZ Clock
CLK14
SIO - LPC 14 MHZ Clock
CLOCKI
CLK33
PCI_0 Port80 - PORT80 33 MHz Clock
GCLK
PCI_1 FWH - FWH 33 MHz Clock
CLK
PCI_2 SIO - SIO 33 MHz Clock
PCI_CLK
PCI_3 IICH 33 MHz Clock
PCICLK
PCI_4 TPM - TPM 33 MHz Clock
LCLK
PCI_5 ITP - ITP 33 MHz Clock
GCLK
CLK48 USB_48 USB - USB 44 MHz Clock
CLK48
