 Normals can also be calculated after import. For this select the ScanWorld and
execute Tools | Estimate Cloud Normals (multiple ScanWorlds can be selected to
run this tool on a batch of files)
Find Pipes Automatically
This command searches all scans for any cylindrical shapes in the clouds and
automatically fits cylinder objects into them.
 Using this option will significantly increase import times.
 Refer to the “Basic Modeling” section for more information.
Apply All
If more than one scan is selected, the above options are applied to all selected.
1.4 Import Options Advanced
The Advanced tab is only available when importing scan data from the P Series Scanners. It
contains various filter settings
Figure 11
