Leica Cyclone - Pipe Run

22 - 32 Module 5.0 - Cyclone Basic Modelling
Data Extraction
Figure 33
3.3 Pipe Run
A quick and convenient way to create a pipe run is to use region grow.
1) Approximately sub-select the group of points representing two pipes connected with an
elbow (see Figure 34). Note this step is not necessary for region growing a pipe run, though
helpful for visualizing.
Figure 34
