1.3 ScanLog
A ScanLog is a quick way to document what has been scanned from which position.
Below you will see the ScanLog for the inner courtyard and on the next page the outside part of
the Blutenburg castle.
Scanner Stations Scans Targets Comments
P40 1
Outer part
360°
Sensitivity = High
Scanmode = Speed
Resolution = 3.1 mm @ 10 m
1, 2, 3,
25, 124
- target 2 must be acquired
manually
P40 2
Inner part
360°
Sensitivity = High
Scanmode = Speed
Resolution = 3.1 mm @ 10 m
1, 3, 25
P40 3
Inner part
360°
Sensitivity = Normal
Scanmode = Speed
Resolution = 3.1 mm @ 10 m
3 - target 3 must be acquired
manually
P40 4
Inner part
360°
Sensitivity = Normal
Scanmode = Speed
Resolution = 3.1 mm @ 10 m
3, 25 - target 25 fitted incorrectly
; must
be deleted and calculated again
- target 33 must be renamed to 3
Table 1
