Coordinate System
A red, green, and blue icon represents the current coordinate system’s
origin (0,0,0). For ScanWorld 1 and ScanWorld 2, the origin is at the local
scanner position.
Summary
ModelSpaces are where we will view, query, and model the point clouds. We access a view to
ModelSpaces via a
ModelSpace View.
To view all of the contents of a
ModelSpace View
, click Viewpoint | View All
Viewpoint | View AllViewpoint | View All
Viewpoint | View All.
As long as the original scan data inside the Scans folder is present, a new
working environment containing a fresh copy of the raw data can be created via
selecting the ModelSpaces folder and executing Create
Create Create
Create |
| |
| ModelSpaces
ModelSpacesModelSpaces
ModelSpaces.
..
.
6.4 ControlSpaces
A ControlSpace is similar to a
ModelSpace View
. It is used as a container for all objects attached
to its parent ScanWorld that are designated as “constraint” objects or possible constraint
objects in the registration of that ScanWorld. Every ScanWorld by default has a ControlSpace.
•
Double
DoubleDouble
Double-
--
-click
clickclick
click a ControlSpace in the
Navigator
to open it.
•
Inspect the ControlSpaces for ScanWorld 1 and ScanWorld 2.
•
Note the tie-points with registration labels in each.
The ControlSpace will contain all objects used in a registration. Every ScanWorld has at least one
ControlSpace.
7 File Management
Rename Objects to reflect use and/or location
You are strongly encouraged to always give specific or highly descriptive names to each of the
ModelSpaces, ModelSpace Views, and Registration Files.
•
Any of the folders or objects can be renamed at any time.
•
The only file name that you cannot change in the
Navigator
is the name of the Database.
