Leica Cyclone - Page 47

Scanner & Scanning Features
Module 1.0
-
Scanning with ScanStation
P30
37
-
60
When the window is closed down by picking the Checkmark button the values for horizontal
and vertical angle are set in the Hz / V Area text boxes, see Figure 32.
Figure 32
At the Scan Mode there are three different settings available:
•
Scan only
•
Images only
•
Scan & Image
(default)
