Xerox Phaser 6300 Service Manual

Theory of Operation 2-23
Developer Drive Assembly
The Developer Drive Motor drives the four developers housed in the Developer Unit.
The drive transmission route differs depending on the print mode. For monochrome
printing, the developer for the K drum is activated as shown in the following figure.
Deve Assy (K)
Developer Drive Motor
Gear D2-IN
Gear D5 (1 Way Clutch)
Gear D7
Gear D8
Gear Developer Input (K)
Mag Roll (K)
s6300-342
