2-24 Phaser 6300/6350 Color Laser Printer Service Manual
The following figure shows the relative positions of the gears being driven during
monochrome printing.
s6300-052
Developer
Drive Motor
Drive Motor
Gear
Gear D2-In
Gear D5
Gear D7
Gear D8
Gear Developer
Input(K)
Front
