Access Control Lists (ACL) | 141

Example

Figure 6-14. show route-map Command Example

Related

Commands

FTOS#show route-map

route-map firpo, permit, sequence 10

Match clauses:

Set clauses:

tag 34

FTOS#

route-map Configures a route map.
