Dell Force10 MXL Blade - Field Description

Data Center Bridging | 173
Example
Figure 9-2. show interface dcbx detail Command Example
Table 9-2 lists the show interface dcbx detail field descriptions.
Table 9-2. show interface dcbx detail Command Example Fields
Field Description
Interface Interface type with chassis slot and port number.
Port-Role Configured the DCBX port role: auto-upstream, auto-downstream, config-source,
or manual.
DCBX Operational Status Operational status (enabled or disabled) used to elect a configuration source and
internally propagate a DCB configuration. The DCBX operational status is the
combination of PFC and ETS operational status.
Configuration Source Specifies whether the port serves as the DCBX configuration source on the switch:
true (yes) or false (no).
Local DCBX
Compatibility mode
DCBX version accepted in a DCB configuration as compatible. In auto-upstream
mode, a port can only received a DCBX version supported on the remote peer.
FTOS(conf)# show interface tengigabitethernet 0/49 dcbx detail
FTOS#show interface te 0/49 dcbx detail
E-ETS Configuration TLV enabled e-ETS Configuration TLV disabled
R-ETS Recommendation TLV enabled r-ETS Recommendation TLV disabled
P-PFC Configuration TLV enabled p-PFC Configuration TLV disabled
F-Application priority for FCOE enabled f-Application Priority for FCOE
disabled
I-Application priority for iSCSI enabled i-Application Priority for iSCSI
disabled
-------------------------------------------------------------------------------
-----------
Interface TenGigabitEthernet 0/49
Remote Mac Address 00:00:00:00:00:11
Port Role is Auto-Upstream
DCBX Operational Status is Enabled
Is Configuration Source? TRUE
Local DCBX Compatibility mode is CEE
Local DCBX Configured mode is CEE
Peer Operating version is CEE
Local DCBX TLVs Transmitted: ErPfi
Local DCBX Status
-----------------
DCBX Operational Version is 0
DCBX Max Version Supported is 0
Sequence Number: 2
Acknowledgment Number: 2
Protocol State: In-Sync
Peer DCBX Status:
----------------
DCBX Operational Version is 0
DCBX Max Version Supported is 255
Sequence Number: 2
Acknowledgment Number: 2
Total DCBX Frames transmitted 27
Total DCBX Frames received 6
Total DCBX Frame errors 0
Total DCBX Frames unrecognized 0
