Dell Force10 MXL Blade - Ip Udp-Broadcast-Address; Ip Udp-Helper Udp-Port

Interfaces | 287
ip udp-broadcast-address
Configure an IP UDP address for broadcast.
Syntax
ip udp-broadcast-address address
To delete the configuration, use the no ip udp-broadcast-address address command.
Parameters
Defaults
Not Configured
Command Modes
INTERFACE (config-if)
Usage
Information
When a UDP broadcast packet is flooded out of an interface, and the outgoing interface is configured
using this command, the outgoing packet’s IP destination address is replaced with the configured
broadcast address.
Command
History
Related
Commands
ip udp-helper udp-port
Enable the UDP broadcast feature on an interface either for all UDP ports or a specified list of UDP
ports.
Syntax
ip udp-helper udp-port [udp-port-list]
To disable the UDP broadcast on a port, use the no ip udp-helper udp-port [udp-port-list] command.
Parameters
Defaults
none
Command Modes
INTERFACE (config-if)
Usage
Information
If you configure the ip helper-address command and ip udp-helper udp-port command, the behavior
is that the UDP broadcast traffic with port numbers 67/68 is unicast relayed to the DHCP server as per
the ip helper-address configuration. This occurs regardless of whether the ip udp-helper udp-port
command contains port numbers 67/68 or not.
If you only configure the ip udp-helper udp-port command, all the UDP broadcast traffic is flooded,
including ports 67/68 traffic if those ports are part of the udp-port-list.
Command
History
address
Enter an IP broadcast address in dotted decimal format (A.B.C.D).
Version 8.3.16.1 Introduced on MXL 10/40GbE Switch IO Module
debug ip udp-helper Enables debug and display the debug information on a console.
show ip udp-helper Displays the configured UDP helper(s) on all interfaces.
udp-port-list
(OPTIONAL) Enter up to 16 comma separated UDP port numbers.
Note: If this option is not used, all UDP Ports are considered by default.
Version 8.3.16.1 Introduced on MXL 10/40GbE Switch IO Module
