Open Shortest Path First (OSPFv2) | 415
Example
Figure 21-10. show ip ospf process-id database network Command Example
Related
Commands
Table 21-6. show ip ospf process-id database network Command Description
Item Description
LS Age Displays the LSA age.
Options Displays the optional capabilities available on router. The following options can be
found in this item:
• TOS-capability or No TOS-capability is displayed depending on whether the router
can support Type of Service.
• DC or No DC is displayed depending on whether the originating router can support
OSPF over demand circuits.
• E or No E is displayed on whether the originating router can accept AS External
LSAs.
LS Type Displays the LSA’s type.
Link State ID Displays the Link State ID.
Advertising Router Identifies the router ID of the LSA’s originating router.
Checksum Identifies the link state sequence number. This number enables you to identify old or
duplicate LSAs.
Length Displays the Fletcher checksum of an LSA’s complete contents.
Network Mask Displays the length in bytes of the LSA.
Attached Router Identifies the IP address of routers attached to the network.
FTOS#show ip ospf 1 data network
OSPF Router with ID (20.20.20.5) (Process ID 1)
Network (Area 0.0.0.0)
LS age: 1372
Options: (No TOS-capability, DC, E)
LS type: Network
Link State ID: 202.10.10.2
Advertising Router: 20.20.20.8
LS Seq Number: 0x80000006
Checksum: 0xa35
Length: 36
Network Mask: /24
Attached Router: 20.20.20.8
Attached Router: 20.20.20.9
Attached Router: 20.20.20.7
Network (Area 0.0.0.1)
LS age: 252
Options: (TOS-capability, No DC, E)
LS type: Network
Link State ID: 192.10.10.2
Advertising Router: 192.10.10.2
LS Seq Number: 0x80000007
Checksum: 0x4309
Length: 36
Network Mask: /24
Attached Router: 192.10.10.2
Attached Router: 20.20.20.1
Attached Router: 20.20.20.5
FTOS#
show ip ospf database Displays OSPF database information.
