Private VLAN (PVLAN) | 445
Figure 23-4. show vlan private-vlan Command Example (Primary)
Figure 23-5. show vlan private-vlan Command Example (Isolated)
Figure 23-6. show vlan private-vlan Command Example (Community)
Figure 23-7. show vlan private-vlan Command Example (Interface)
If the VLAN ID is that of a primary VLAN, then the entire private VLAN output will be displayed, as
shown in Figure 23-8. If the VLAN ID is a secondary VLAN, only its primary VLAN and its particular
secondary VLAN properties will be displayed, as shown in Figure 23-9.
Figure 23-8. Output of show vlan private-vlan (primary)
Figure 23-9. Output of show vlan private-vlan (secondary)
FTOS# show vlan private-vlan primary
Primary Secondary Type Active Ports
------- --------- --------- ------ ------------------------
10 primary Yes TenGig 2/1,3
20 primary Yes TenGig 3/1,3
FTOS# show vlan private-vlan isolated
Primary Secondary Type Active Ports
------- --------- --------- ------ ------------------------
10 primary Yes TenGig 2/1,3
100 isolated Yes TenGig 2/2,4-6
200 isolated Yes TenGig 3/2,4-6
FTOS# show vlan private-vlan community
Primary Secondary Type Active Ports
------- --------- --------- ------ ------------------------
10 primary Yes TenGig 2/1,3
101 community Yes TenGig 2/7-10
20 primary Yes Po 10, 12-13
TenGig 3/1
201 community No
202 community Yes TenGig 3/11-12
FTOS# show vlan private-vlan interface TenGig 2/1
Primary Secondary Type Active Ports
------- --------- --------- ------ ------------------------
10 primary Yes TenGig 2/1
FTOS# show vlan private-vlan 10
Primary Secondary Type Active Ports
------- --------- --------- ------ ------------------------
10 primary Yes TenGig 2/1,3
1020 isolated Yes TenGig 0/4
101 community Yes TenGig 2/7-10
FTOS#show vlan private-vlan 102
Primary Secondary Type Active Ports
------- --------- --------- ------ ------------------------------------------
10 Primary Yes Po 1
TenGig 0/2
102 Isolated Yeso TenGig 0/4
