*1 The XSCF of BB#01 is in the standby state.
primary#
ldm list-domain
NAME STATE FLAGS CONS VCPU MEMORY UTIL NORM UPTIME
primary active -n-cv- UART 32 16G 1.3% 1.3% 7d 17h
26m (*1)
guest active -n---- 5000 32 16G 0.0% 0.0% 7d 16h
(*2)
ldom active -n---- 5001 32 32G 0.0% 0.0% 7d 14h
17m (*3)
primary# ldm
list-services
VCC
NAME LDOM PORT-RANGE
primary-vcc0
primary 5000-5100
VSW
NAME LDOM MAC NET-DEV ID DEVICE
LINKPROP
DEFAULT-VLAN-ID PVID VID MTU MODE
INTER-VNET-LINK
primary-vsw0
primary 00:14:4f:fb:e1:a8 net0 0
switch@0
1 1 1500 on
primary-vsw4
primary 00:14:4f:f8:42:2f net4 1
switch@1
1 1 1500 on
VDS
NAME LDOM VOLUME OPTIONS MPGROUP DEVICE
primary-vds0
primary vdisk00 /dev/zvol/dsk/rpool/
export/ovm/vdisk00
vdisk01
/dev/zvol/dsk/rpool/
export/ovm/vdisk01
vol_iso
ro /export/ovm/sol11u3_
iso/sol-11_3-text-sparc.iso
vdisk10
/dev/zvol/dsk/rpool/
Next, log in to Oracle Solaris on the control domain in the physical partition
containing the SPARC M12-2S to be released. Then, check the operation status of
logical domains and the assignment status of resources.
3.
Check the operation status of the logical domains defined in PPAR ID#00.
The following example assumes
that the user logs in to Oracle Solaris on the
control domain and checks the defined logical domains and operation status.
4.
Check the list of the set virtual services for the control domain.
- Virtual console service: The port numbers that the guest domain can use for
primary-vcc0 for the virtual
console service range from 5000 to 5100.
- Virtual switch: Physical LAN ports net0 and net4 are assigned to virtual
switches primary-vsw0 and primary-vsw4, respectively.
- Virtual disk service: vdisk00, vdisk01, vdisk10, vdisk11, and vol_iso are
assigned to primary-vds0 for the virtual disk service.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023298
