Fujitsu Oracle SPARC M12-2

Examples of label indications
BB00-DUAL
BB01-DUAL
BB00-DUAL
BB01-DUAL
BB00-DUAL
BB01-DUAL
BB00-DUAL
BB01-DUAL
2.
Write the port number on labels.
The replacement XSCF DUAL control cable comes with the labels shown in
Figure 21-3. Write the connected port on these labels. For the XSCF DUAL
control cable, use LABEL-E. As in the example shown in Figure 21-3, write the
port number identified in step
1 on two labels.
Figure 21-3
Accompanying Labels and Examples of Label Indications
3.
Place the server in the cold state.
To perform maintenance after every SPARC M12-2S was placed in the cold state
without using the maintenance menu, remove the power cords of every SPARC
M12-2S. For details on handling power
cords, see "9.8.2 Removing the Power
Cords."
