GD32F3x0 User Manual

562

No.

Interrupt event in HDMI-CEC

Event flag

Interrupt enable bit

Transmit Byte buffer underrun

TUIE

Transmit error

TERR

TERRIE

Transmit acknowledge error

TAERR

TAERRIE

Byte Received

BRIE

Reception end

REND

RENDIE

Receive Overrun

ROIE

Bit rising error

BRE

BREIE

Bit Period Short Error

BPSE

BPSEIE

Bit Period Long Error

BPLE

BPLEIE

RX acknowledge error

RAE

RAEIE

Note: Any HDMI-CEC interrupt will wake up the chip from Deep-sleep Mode.
