Maximum Current
Consumption 90 mA @ 24 VDC
NOTE 1. Outputs #1, #2, #3, and #4 share a common signal.
All other outputs have individual contacts.
TRANSISTOR Number of Outputs 4; each can be individually wired
OUTPUTS as pnp (source) or npn (sink)
Output Type pnp P-MOSFET (open drain)
npn open collector
Galvanic Isolation Yes
Output Current pnp 0.5 Amp max (per output)
Total current: 2 A max (per group)
npn 50 mA max (per output)
Total current: 150 mA (per group)
Maximum Frequency Resistive Load 20 Hz
Inductive Load 0.5 Hz
ON Voltage Drop pnp 0.5 VDC max
npn 0.85 VDC max
Short Circuit Protection Yes (pnp only)
Power Supply
Operating Voltage 20.4 to 28.8 VDC
Power Supply
Nominal Operating Voltage 24 VDC
npn (sink) Power Supply 3.5 V to 28.8 VDC (unrelated to Remote
Operating Voltage Relay Module voltage or Controller voltage)
ENVIRON Operating Temperature 0 to 50°C (32 to 122°F) -
MENTAL
Storage Temperature -20 to 60°C (-4to 140°F)
Relative Humidity (RH) 5% to 95% (non-condensing)
Dimensions 138 W x 23 H x 123 mm D
(5.43 W x 0.9 H x 4.84" D)
Weight 222 g (7.8 oz)
4-10

Hach sc200 Specifications

General

Enclosure Rating	NEMA 4X/IP66
Operating Temperature	-20 to 60 °C (-4 to 140 °F)
Ambient Temperature	-20 to 60 °C (-4 to 140 °F)
Enclosure Material	Polycarbonate
Operating Humidity	0 to 95% non-condensing
Relay Outputs	Up to 4 SPDT relays
Storage Conditions	-40 to 70 °C (-40 to 158 °F)
Display	Graphical LCD
Inputs	2 digital sensor inputs
Outputs	4-20 mA
Power Supply	100 to 240 VAC, 50/60 Hz
Analog Outputs	2 or 4, 0/4-20 mA
Certifications	CE
Communication	Modbus RTU, HART
Dimensions	144 x 144 mm
Mounting	Panel mount
Output	4-20 mA
Power Requirements (Voltage)	100 to 240 VAC
Warranty	1 year
Weight	1.2 kg
