• For systems that use six-digit addressing, 4XXXXX:
• The first digit is an internal system requirement and does not
appear in the communications packet. The base address is
440000, and the first valid address is 440001.
Table 3-4. ModBUS Factory Configuration Data (Read Only)
DESCRIPTION ADDRESS POSSIBLE VALUES
Device Type Base+1 3(Ultima X3 US)
4(Ultima X3 Europe)
Firmware Version Base+2 0..32767 Integer,
divide by 100 for range
00.00 to 99.99
Relays Option Installed Base+3 0-Relays not installed,
1-Relays installed
Reserved for future use Base+4
Date of Mfg Year, Sensor 1 Base+5 20XX
Date of Mfg Month, Sensor 1 Base+6 1..12
Date of Mfg Day, Sensor 1 Base+7 1..31
Date of Mfg Year, Sensor 2 Base+8 20XX
Date of Mfg Month, Sensor 2 Base+9 1..12
Date of Mfg Day, Sensor 2 Base+10 1..31
Date of Mfg Year, Sensor 3 Base+11 20XX
Date of Mfg Month, Sensor 3 Base+12 1..12
Date of Mfg Day, Sensor 3 Base+13 1..31
Full Scale Range-
Default Sensor 1 Base+14 Single Precision Float
Full Scale Range-
Default Sensor 2 Base+16 Single Precision Float
Full Scale Range-
Default Sensor 3 Base+18 Single Precision Float
3-3

Hach sc200 Specifications

General

Enclosure Rating	NEMA 4X/IP66
Operating Temperature	-20 to 60 °C (-4 to 140 °F)
Ambient Temperature	-20 to 60 °C (-4 to 140 °F)
Enclosure Material	Polycarbonate
Operating Humidity	0 to 95% non-condensing
Relay Outputs	Up to 4 SPDT relays
Storage Conditions	-40 to 70 °C (-40 to 158 °F)
Display	Graphical LCD
Inputs	2 digital sensor inputs
Outputs	4-20 mA
Power Supply	100 to 240 VAC, 50/60 Hz
Analog Outputs	2 or 4, 0/4-20 mA
Certifications	CE
Communication	Modbus RTU, HART
Dimensions	144 x 144 mm
Mounting	Panel mount
Output	4-20 mA
Power Requirements (Voltage)	100 to 240 VAC
Warranty	1 year
Weight	1.2 kg
