Option Description
Set Date/Time Sets the controller time and date (refer to Update the
date and time on page 36)
Datalog setup Configures data logging options. Available only if
Calculation has been setup. At least one sensor must
be attached to enter a calculation (refer to Set the
datalog mode and interval on page 37)
Manage Data Select the device from the list of installed
components to view the data or event log
Error Hold Mode Hold Outputs—Holds outputs at last known value
when controller loses communication with the
sensor.
Transfer Outputs—Switches to transfer mode when
controller loses communication with the sensor.
Outputs transfer to a pre-defined value.
Calculation Configures the controller math function (refer to Set
up a calculation on page 37)
sc200 Information S/W VER:—Displays the current version of controller
software
Bootloader VER:—Displays the current Bootloader
version. The Bootloader is a file that loads the main
operating system for the controller
S/N:—Displays the controller serial number
Version:—Displays the current version of controller
hardware
Discrete Input Setup Configures three discrete input channels (refer to Set
up the discrete inputs on page 37)
Language Assigns the language used in the controller (refer to
Update the display language on page 38)
2. Select an option and push ENTER to activate the menu item.
Advanced operation
Security setup
Enable or disable the passcode
By default the passcode option is disabled and all configuration settings
and calibrations can be changed. When the passcode function is
enabled, access to Sensor calibration and Test/Maint menus requires a
passcode.
To enable the passcode:
1. From the Settings Menu, select sc200 Setup and push the ENTER
key.
2. Select Security Setup and push the ENTER key.
3. Select Set Passcode and push the ENTER key.
4. Select Disabled or Enabled and push the ENTER key.
The passcode is enabled.
5. Push the BACK key to return to the sc200 Setup Menu, or push the
MENU key to return to the Settings Menu.
Edit the passcode
The passcode is factory set to SC200. The Edit Passcode menu option
appears in the Security Setup menu only after the passcode feature is
enabled and a valid passcode has been entered.
A passcode consists of up to six upper or lower-case alpha, numeric and
special characters. Passcodes are case-sensitive.
To edit the passcode:
1. Make sure the passcode is enabled. Refer to Enable or disable the
passcode on page 24 for information on how to enable the passcode.
2. From the Settings menu, select Security Setup and push ENTER.
3. Use the arrow keys to enter the current valid passcode and push
ENTER.
The Edit Passcode option appears in the Security Setup menu.
4. Select Edit Pass Code and push ENTER.
The Edit Pass Code screen appears.
5. Use the arrow keys to edit the passcode and push ENTER.
24 (nglisK
