UPS MAINTENANCE

Eaton

9130 UPS (700–3000 VA) User's Guide S 164201718 Rev 3 www.eaton.com/powerquality

10. Replace the EBM front cover.

To replace the cover, verify that the EBM cables are routed through

the EBM cover knockouts, then slide the cover from the left to the

right until it connects with the cover hook near the left side of the

EBM cabinet. Reinstall the two screws on the right side of the front

cover. For reference, see Figure 27 on page 69.

Repeat for each additional EBM.

11. Verify that all wiring connecting the UPS and EBM(s) is installed

behind the front covers and is inaccessible to users.

Replacing Tower EBMs

C A U T I O N

The EBM is heavy (see page 78). Lifting the cabinet requires a minimum of two people.

To replace the EBMs:

1. Unplug the EBM cable from the UPS.

If additional EBMs are installed, unplug the EBM cable from the

battery connector on each EBM.

2. Replace the EBM(s). See “Recycling the Used Battery or UPS” on

page 73 for proper disposal.

3. For each replaced EBM, remove the cable retention clip covering

the battery connector(s), as shown in Figure 16 on page 33. Retain

the clips and screws.

C A U T I O N

A small amount of arcing may occur when connecting an EBM to the UPS. This is normal and

will not harm personnel. Insert the EBM cable into the UPS battery connector quickly and

firmly.

4. Plug the EBM cable(s) into the battery connector(s) as shown in

Figure 16 on page 33. Up to four EBMs may be connected to the

UPS.
