While every precaution has been taken to ensure accuracy and completeness in this manual, EGS Electrical Group, LLC. assumes no responsibility, and disclaims all liability for damages resulting from use of this information or for any errors or omissions. The
SolaHD and Emerson logos are registered in the U.S. Patent and Trademark Oce. All other product or service names are the property of their registered owners. ©2009 EGS Electrical Group, LLC. All rights reserved. Specications are subject to change without notice.
Table 1: Voltage Ratings & Power Source Congurations
Model Nominal Voltage (50/60 Hz) System Conguration Source Conguration
STV 25K-10S 120 V ac Single Phase, 2W + G
STV 25K-24S 240 V ac Single Phase, 2W + G
4.2 DIN Rail Mounting
1. Tilt unit as illustrated.
2. Put unit onto the DIN rail.
3. Push unit downward until it stops.
4. Push at the lower front edge to lock.
5. Gently shake the unit to ensure that it is secure.
NOTE: Press the button located at the top (rear) of the enclosure downward to unlock and remove the unit from the DIN rail.
4.3 Applying Power
Apply power to the unit and assure status indications are normal. Under normal conditions, the green LED is illuminated.
If the green LED is not illuminated, check all connections and ensure reliable and proper voltages are supplied to the unit. For further assistance,
please contact SolaHD Technical Support at (800) 377-4384/(847) 368-6000 or via e-mail at tech@solahd.com.
5.0 Registration & Warranty
5.1 Product Registration
To register your product for updates and information on service and support, visit our Web site at: http://www.solahd.com/support/registration.htm
5.2 Warranty Information
Please see the enclosed “Terms & Conditions of Sale”.
