Model 6 Motor Control Centers 80459-641-01E
Section 1—About the Model 6 Motor Control Center 10/2012
© 1999–2012 Schneider Electric All Rights Reserved12
ENGLISH
30072-013-98
Motor Logic Plus™ Programmable Solid-State
Overload Relay
3020IM9806
PowerLogic Circuit Monitor Series 2000 Reference
Manual
30072-013-99 Motor Logic Plus Solutions Software 63230-400-207
PowerLogic Circuit Monitor Series 3000 Reference
Manual
30072-013-101 Motor Logic Plus Lug-Lug Kit 63230-300-213
PowerLogic Circuit Monitor Series 4000 Reference
Manual
30072-013-102 Motor Logic Plus Network Communication Module 0100PL1201 Schneider Electric Digest 176
30072-013-52 AC Magnetic Contactors and Starters, Size 00 63230-500-224 PM820, PM850, PM870 Installation
30072-013-22 AC Magnetic Contactors and Starters, Size 0 63230-500-225 PM820, PM850, PM870 Reference Manual
30072-013-23 AC Magnetic Contactors and Starters, Size 1
Table 2: iMCC-Related Literature
Publication No. Title Publication No. Title
atv71_parameters_en
Altivar
£
71 Communication Parameters User’s
Manual
1639576
TeSys T LTM R Modbus/TCP Motor Management
Controller Quick Start Guide
atv71_programming_manual_en Altivar 71 Programming Manual 1639581
TeSys T LTM CU Control Operator Unit User’s
Manual
atv71_Modbus_EN
Altivar 71 Modbus
®
/Uni-Telway™ Card—
Modbus protocol
1639508_01a55 LTM R - Instruction Sheet
atv71_Uni-Telway_EN
Altivar 71 Modbus/Uni-Telway card—
UniTelway protocol
1639509_01a55 LTM E - Instruction Sheet
BBV46391 Altivar 312 AC Drive Installation Manual 1639582_01a55 LTM CU - Instruction Sheet
BBV46385 Altivar 312 AC Drive Programming Manual 840USE10000 Modicon™ TSX Quantum Automation Series
890USE10300
Modicon Modbus Plus™ Network BM85 Bridge
Multiplexer User’s Guide
840USE11300 Modicon XMIT Function Block
Modicon TSX Quantum
Automation Series
www.modicon.com/specguide98/
840USE11600 Quantum NOE 771 X0 Ethernet Modules User Guide
PI-MBUS-300 Modicon
Modbus Protocol Reference Guide 870USE00200 TSX Momentum™ I/0 Base User Guide
30072-013-98
Motor Logic Plus™ Programmable Solid-State
Overload Relay
870USE10100
Modicon TSX Momentum M1 Processor Adapter and
Option Adapter User Manual
30072-013-99 Solutions Software for Motor Logic Plus SSOL 870USE11400 Ethernet Communications Adapter
30072-013-101 Motor Logic Plus Lug-Lug Kit 890USE10000
Modicon Modbus Plus Network Planning/Installation
Guide
30072-013-102
Motor Logic Plus Network Communication
Module
3000DB0001
PowerLogic™ System Architecture and Application
Guide
30072-450-61 Altistart™ 48 Y-Range Soft Start Controllers 3020IB9818
PowerLogic Ethernet Communication Module,
Models ECM-2000 and ECM-RM
1639501
TeSys™ T LTM R Modbus Motor Management
Controller User’s Manual
63230-500-200
PowerLogic Series 800 Power Meter Installation
Manual—PM810
1639502
TeSys T LTM R PROFIBUS Motor Management
Controller User's Manual
63230-500-224
PowerLogic Series 800 Power Meter Installation
Manual—PM820, PM850, PM870
1639503
TeSys T LTM R CANopen Motor Management
Controller User's Manual
63230-400-204
PowerLogic Circuit Monitor Series 3000 Installation
Manual
1639504
TeSys T LTM R DeviceNet™ Motor
Management Controller User’s Manual
63230-300-209
PowerLogic Circuit Monitor Series 4000 Installation
Manual
1639505
TeSys T LTM R Modbus/TCP Motor
Management Controller User's Manual
3050IM9601 PowerLogic Ethernet Gateway
1639572
TeSys T LTM R Modbus Motor Management
Controller Quick Start Guide
3080HO9601 System Manager™ Software SMS-3000
1639573
TeSys T LTM R PROFIBUS-DP
®
Motor
Management Controller Quick Start Guide
3080IB9803 PL, PowerLogic System Manager 3000
1639574
TeSys T LTM R CANopen Motor Management
Controller Quick Start Guide
3080IM9603 Ethernet Driver for System Manager
1639575
TeSys T LTM R DeviceNet Motor Management
Controller Quick Start Guide
Table 1: MCC-Related Literature (continued)
Publication No. Title Publication No. Title
To Next Page
