instance, the ModCon75 Controller will round to the nearest
single decimal.
•F7:
• Sends all changes to the ModCon75 Controller
• Sets Controller relays (connections located on back of unit) to
activate according to caution, warning or alarm settings set on
the Choose Zone event screen
• Verifies that all values were sent successfully.
NOTE: If user does not press F7, the changes will not be made.
Combustible sensors cannot be set to a range of 61-100.
Figure 6-14. Displays all Presets
before Downloading to the Unit
6-11

Hach sc200 Specifications

General

Enclosure Rating	NEMA 4X/IP66
Operating Temperature	-20 to 60 °C (-4 to 140 °F)
Ambient Temperature	-20 to 60 °C (-4 to 140 °F)
Enclosure Material	Polycarbonate
Operating Humidity	0 to 95% non-condensing
Relay Outputs	Up to 4 SPDT relays
Storage Conditions	-40 to 70 °C (-40 to 158 °F)
Display	Graphical LCD
Inputs	2 digital sensor inputs
Outputs	4-20 mA
Power Supply	100 to 240 VAC, 50/60 Hz
Analog Outputs	2 or 4, 0/4-20 mA
Certifications	CE
Communication	Modbus RTU, HART
Dimensions	144 x 144 mm
Mounting	Panel mount
Output	4-20 mA
Power Requirements (Voltage)	100 to 240 VAC
Warranty	1 year
Weight	1.2 kg
