Option Description
Simulation (only
displays if sensors
or modules are
connected)
After the sim value is entered, the controller outputs
this value as if it was the value sent from the sensor.
The simulation stops after the user exits the screen.
Source-
• <Module 1>
• <Module 2>
(Footer displays current source selection)
Parameter—Source measurement type (footer
displays current source selection)
Sim value—Use arrow keys to change value (footer
displays current source selection)
Modbus stats Displays Error and Good count stats for selected port.
• Sensor port 1, 2, 3 or 4
• Network port
• Service port
• Clear stats
System data Displays the current system current, temperature and
voltage data.
Warning and error conditions
Follow the steps below to acknowledge controller warnings.
1. From the Settings menu, select Diagnostics and push ENTER.
2. Select the device (controller, sensor, network card) with the warning
or error and push ENTER.
3. Select the warning, error or event list and push ENTER.
4. Select Yes and push ENTER to acknowledge the warning.
1ote (rrors cannot Ee acNnoZledged.
5. For more information on a specific warning, error or event, refer to
the device manual.
Device scan information
Display message Action
Installing device...please wait The controller has found a new device.
No action is necessary. The controller
automatically performs an installation
process for the new device and
displays the main measurement screen
of the device installed in the number
one position.
Device missing <device id> A previously installed device has been
removed from the controller or is not
detected.
• Push the Enter key to continue.
• Push the left arrow key to select or
de-select a missing device.
• Push the Enter key to delete the
missing device.
The controller will display the main
measurement screen for the device in
the number one position.
1ote 7Kis Pessage also displays ZKen a
device is Pissing and a neZ device Kas Eeen
installed. $fter tKe Pissing device is deleted
tKe controller autoPatically installs tKe neZ
device and displays Installing device...please
Zait. 7Ke controller tKen displays tKe Pain
PeasurePent screen for tKe device installed
in tKe nuPEer one position.
Replacement parts and accessories
1ote Product and $rticle nuPEers Pay vary for soPe selling regions. Contact tKe
appropriate distriEutor or refer to tKe coPpany ZeEsite for contact inforPation.
Description Item number
4 GB Secure Digital Memory (SD) card 9218100
Connector kit for digital sensor 9201000
(nglisK 45
