COMMUNICATION

Eaton

9130 UPS (700–3000 VA) User's Guide S 164201718 Rev 3 www.eaton.com/powerquality

Programmable Signal Inputs

The UPS incorporates four programmable signal inputs: one RS-232

input, two connectivity card inputs, and one REPO terminal input. See

Figure 18 on page 53 for the locations of the ports. Configure the inputs

with the “Signal Inputs” setting in “User Settings” on page 40.

Table 6 shows the programmable settings for the signal inputs. Table 7

shows the operation logic for the signal inputs.

Table 6. Programmable Signal Inputs

Signal Description

Not Used The input operates only as a serial input (RxD) or has no function.

Force Bypass If active, the UPS is forced to static bypass operation regardless of

the bypass status.

Remote Shutdown If active, the UPS output turns off after a user-defined remote

shutdown delay. The batteries continue charging. Inactive input

does not abort the shutdown countdown and does not cause the

UPS to start up automatically.

Delayed

Shutdown

(and restart)

If active, the UPS output turns off after a user-defined delayed

shutdown delay. The batteries continue charging. Inactive input

does not abort the shutdown countdown but will cause the UPS to

start up automatically if the input voltage exists.

On Generator If active, synchronization is disabled and the UPS transfers to

bypass.

Building Alarm 1 If active, the UPS generates the “Building Alarm 1” alarm.

Table 7. Polarity Options

Input Description

High Active state on high voltage (+Udc) level

Low Active state on low voltage (GND or -Udc) level
