80459-641-01E Model 6 Motor Control Centers
10/2012 Section 12—Insulation Resistance
© 1999–2012 Schneider Electric All Rights Reserved
105
ENGLISH
Thermal Overload Unit Selection This section identifies the thermal overload units needed for the starters
specified in an order. Tables are based on motor full-load amps and provide
the catalog number for the appropriate thermal units to be used at that
current rating.
Melting Alloy Overload Selection Tables for Combination Starter Units
Size 1 Size 2
Motor
Full-Load
Current (A)
Thermal Unit
Number
Motor
Full-Load
Current (A)
Thermal Unit
Number
Motor
Full-Load
Current (A)
Thermal Unit
Number
Motor
Full-Load
Current (A)
Thermal Unit
Number
0.56–0.63 B 0.81 4.12–4.70 B 6.90 3.94–4.45 B 6.90 14.0–15.8 B 25
0.64–0.68 B 0.92 4.71–5.21 B 7.70 4.46–4.97 B 7.70 15.9–17.9 B 28
0.69–0.77 B 1.03 5.22–5.53 B 8.20 4.98–5.28 B 8.20 18.0–19.9 B 32
0.78–0.85 B 1.16 5.54–6.17 B 9.10 5.29–5.97 B 9.10 20.0–22.8 B 36
0.86–0.97 B 1.30 6.18–7.02 B 10.2 5.98–6.89 B 10.2 22.9–25.4 B 40
0.98–1.09 B 1.45 7.03–7.92 B 11.5 6.90–7.92 B 11.5 25.5–28.9 B 45
1.10–1.21 B 1.67 7.93–8.61 B 12.8 7.93–8.71 B 12.8 29.0–30.8 B 50
1.22–1.33 B 1.88 8.62–9.17 B 14 8.72–9.27 B 14.0 30.9–32.5 B 56
1.34–1.53 B 2.10 9.18–10.0 B 15.5 9.28–10.2 B 15.5 32.6–34.9 B 62
1.54–1.73 B 2.40 10.1–11.0 B 17.5 10.3–11.4 B 17.5 35.0–39.7 B 70
1.74–1.89 B 2.65 11.1–11.8 B 19.5 11.5–12.3 B 19.5 39.8–44.7 B 79
1.90–2.17 B 3.00 11.9–13.5 B 22 12.4–13.9 B 22
2.18–2.53 B 3.30 13.6–15.3 B 25
2.54–2.87 B 3.70 15.4–17.4 B 28
2.88–3.22 B 4.15 17.5–19.4 B 32
3.23–3.49 B 4.85 19.5–22.2 B 36
3.50–3.85 B 5.50 22.3–25.1 B 40
3.86–4.11 B 6.25 25.2–27.0 B 45
Size 3 Size 4
Motor
Full-Load
Current (A)
Thermal Unit
Number
Motor
Full-Load
Current (A)
Thermal Unit
Number
Motor
Full-Load
Current (A)
Thermal Unit
Number
Motor
Full-Load
Current (A)
Thermal Unit
Number
14.0–14.9 CC 20.9 36.9–39.8 CC 59.4 44.0–46.8 CC 64.3 73.0–78.1 CC 112
15.0–16.2 CC 22.8 39.9–42.3 CC 64.3 46.9–50.6 CC 68.5 78.2–83.9 CC 121
16.3–17.2 CC 24.6 42.4–45.7 CC 68.5 50.7–54.5 CC 74.6 84.0–91.1 CC 132
17.3–18.7 CC 26.3 45.8–49.2 CC 74.6 54.6–58.4 CC 81.5 91.2–97.5 CC 143
18.8–20.2 CC 28.8 49.3–52.8 CC 81.5 58.5–62.9 CC 87.7 97.6–104 CC 156
20.3–21.7 CC 31.0 52.9–56.8 CC 87.7 63.0–67.7 CC 94.0 105–113 CC 167
21.8–23.3 CC 33.3 56.9–61.2 CC 94.0 67.8–72.9 CC 103 114–133 CC 180
23.4–25.2 CC 36.4 61.3–66.1 CC 103
25.3–27.1 CC 39.6 66.2–71.2 CC 112
27.2–29.4 CC 42.7 71.3–76.7 CC 121
29.5–31.6 CC 46.6 76.8–82.9 CC 132
31.7–34.0 CC 50.1 83.0–90.0 CC 143
34.1–36.8 CC 54.5

Hach sc200 Specifications

General

Enclosure Rating	NEMA 4X/IP66
Operating Temperature	-20 to 60 °C (-4 to 140 °F)
Ambient Temperature	-20 to 60 °C (-4 to 140 °F)
Enclosure Material	Polycarbonate
Operating Humidity	0 to 95% non-condensing
Relay Outputs	Up to 4 SPDT relays
Storage Conditions	-40 to 70 °C (-40 to 158 °F)
Display	Graphical LCD
Inputs	2 digital sensor inputs
Outputs	4-20 mA
Power Supply	100 to 240 VAC, 50/60 Hz
Analog Outputs	2 or 4, 0/4-20 mA
Certifications	CE
Communication	Modbus RTU, HART
Dimensions	144 x 144 mm
Mounting	Panel mount
Output	4-20 mA
Power Requirements (Voltage)	100 to 240 VAC
Warranty	1 year
Weight	1.2 kg
