Model 6 Motor Control Centers 80459-641-01E
Section 9—iMCC 10/2012
© 1999–2012 Schneider Electric All Rights Reserved78
ENGLISH
Figure 109: Typical Cabling Scheme for DeviceNet™ and CANopen (8A cable)
Section 1 Section 2
Single tap trunk cable
(80420-921-01)
6-tap trunk cable assembly
(80420-915-50)
Female terminator
(DN150)
Device cable
(80420-916-01)
20 in. (508 mm) trunk cable
(80420-918-01)
Male terminator
(DN100)
Male cap (D970CAPR)
Mini-mini tee
(DN3020)
NOTE: Shield must be grounded
at one end only.
Orderable
Item
Part
Number
Mini female
field attachable
connector
1A5000-34DN
Mini male field
attachable
connector
1A5006-34DN
25 in. (635 mm)
trunk cable
80420-919-01
30 in. (762 mm)
trunk cable
80420-920-01
35 in. (889 mm)
trunk cable
80420-921-01

Hach sc200 Specifications

General

Enclosure Rating	NEMA 4X/IP66
Operating Temperature	-20 to 60 °C (-4 to 140 °F)
Ambient Temperature	-20 to 60 °C (-4 to 140 °F)
Enclosure Material	Polycarbonate
Operating Humidity	0 to 95% non-condensing
Relay Outputs	Up to 4 SPDT relays
Storage Conditions	-40 to 70 °C (-40 to 158 °F)
Display	Graphical LCD
Inputs	2 digital sensor inputs
Outputs	4-20 mA
Power Supply	100 to 240 VAC, 50/60 Hz
Analog Outputs	2 or 4, 0/4-20 mA
Certifications	CE
Communication	Modbus RTU, HART
Dimensions	144 x 144 mm
Mounting	Panel mount
Output	4-20 mA
Power Requirements (Voltage)	100 to 240 VAC
Warranty	1 year
Weight	1.2 kg
