Sixnet Slim Line Switch Installation Guide Page 15 of 30
0.15"
[0.38 cm]
5.20"
[13.21 cm]
0.35"
[0.88 cm]
#6 screw
#8 screw
#10 screw
#12 screw
Direct to panel
mounting guide
for newer models
Panel mounting ears on
newer models
accept up to a #12 screw
[12.83 cm]
For #6 screw: 5.05"
[12.95 cm]
For #8 screw: 5.10"
[13.08 cm]
For #10 screw: 5.15"
[13.21 cm]
For #12 screw: 5.20"
2.60"
[6.60 cm]
2.60"
[6.60 cm]
Typical for SFP Xcvrs
1.92"
[4.88 cm]
0.39"
[0.99 cm]
3.80"
[9.65 cm]
5.05"
[12.83 cm]
SFP Fiber
Ports
Removable DIN clip
for direct panel mounting
Removable
Screw Block
Panel mounting ears
accept up to a #6
screw on earlier models
and up to a #12 screw
on newer models.
Snaps to
standard
DIN Rail
EN50022
(35 mm)
1.88"
[4.78 cm]
Console
Ports
4.70"
[11.94 cm]
0.50"
[1.27 cm]
1.37"
[3.49 cm]
2.75"
[6.98 cm]
Mechanical Dimensions for SL/SLX-8MG with 8 Gigabit Ports
#6 screw
#8 screw
#10 screw
#12 screw
Panel mounting ears
accept up to a #12 screw
Direct to panel
mounting guide
Snaps to
standard
DIN Rail
EN50022
(35 mm)
Removable
Screw Block
Removable DIN
clip for direct
panel mounting
Panel mounting ears
accept up to
a #12 screw
2.76"
[7.01 cm]
2.76"
[7.01 cm]
0.35"
[0.88 cm]
0.39"
[0.99 cm]
5.52"
[14.02 cm]
2.15"
[5.46 cm]
2.15"
[5.46 cm]
Typical for SFP Xcvrs
0.50" [1.27 cm]
6.02"
[15.29 cm]
1.63"
[4.13 cm]
Mechanical Dimensions for SLX-10MG-1
