Sixnet Slim Line Switch Installation Guide Page 14 of 30
2.60"
[6.60 cm]
2.60"
[6.60 cm]
3.82"
[9.70 cm]
5.05"
[12.83 cm]
for #6
screw
Removable
Screw Block
1.60"
[4.07 cm]
5.20"
[13.21 cm]
0.80"
[2.04 cm]
0.40"
[1.02 cm]
typical
0.15"
[0.38 cm]
0.39"
[0.99 cm]
1.92"
[4.88 cm]
1.90"
[4.83 cm]
#6 screw
#8 screw
#10 screw
#12 screw
Direct to panel
mounting guide
for newer models
Panel mounting ears on
newer models accept
up to a #12 screw
[12.83 cm]
For #6 screw: 5.05"
[12.95 cm]
For #8 screw: 5.10"
[13.08 cm]
For #10 screw: 5.15"
[13.21 cm]
For #12 screw: 5.20"
Console
Port(s)
Snaps to
standard
DIN Rail
EN50022
(35 mm)
SC Fiber
ST Fiber
Removable DIN clip for
direct panel mounting
Panel mounting ears accept
up to a #6 screw on older
models (see to the right for
newer models)
Mechanical Dimensions for SL/SLX-8ES-6/7 with 3 Fiber Ports
2.60"
[6.60 cm]
2.60"
[6.60 cm]
3.82"
[9.70 cm]
5.05"
[12.83 cm]
for #6
screw
Removable
Screw Block
1.60"
[4.07 cm]
5.20"
[13.21 cm]
0.80"
[2.04 cm]
0.40"
[1.02 cm]
typical
0.15"
[0.38 cm]
1.92"
[4.88 cm]
1.90"
[4.83 cm]
For #12 screw: 5.20"
[13.21 cm]
For #10 screw: 5.15"
[13.08 cm]
For #8 screw: 5.10"
[12.95 cm]
For #6 screw: 5.05"
[12.83 cm]
Panel mounting ears on
newer models accept
up to a #12 screw
Direct to panel
mounting guide
for newer models
#12 screw
#10 screw
#8 screw
#6 screw
SC Fiber
ST Fiber
Snaps to
standard
DIN Rail
EN50022
(35 mm)
Removable DIN clip for
direct panel mounting
Panel mounting ears accept
up to a #6 screw on older
models (see to the right for
newer models)
Console
Port(s)
0.39"
[0.99 cm]
Mechanical Dimensions for SL/SLX-8MS-8/9 with 4 Fiber Ports

Hach sc200 Specifications

General

Enclosure Rating	NEMA 4X/IP66
Operating Temperature	-20 to 60 °C (-4 to 140 °F)
Ambient Temperature	-20 to 60 °C (-4 to 140 °F)
Enclosure Material	Polycarbonate
Operating Humidity	0 to 95% non-condensing
Relay Outputs	Up to 4 SPDT relays
Storage Conditions	-40 to 70 °C (-40 to 158 °F)
Display	Graphical LCD
Inputs	2 digital sensor inputs
Outputs	4-20 mA
Power Supply	100 to 240 VAC, 50/60 Hz
Analog Outputs	2 or 4, 0/4-20 mA
Certifications	CE
Communication	Modbus RTU, HART
Dimensions	144 x 144 mm
Mounting	Panel mount
Output	4-20 mA
Power Requirements (Voltage)	100 to 240 VAC
Warranty	1 year
Weight	1.2 kg
