Sixnet Slim Line Switch Installation Guide Page 21 of 30
-
+
+
-
Alarm
Output
Load
(opt.)
Alarm
Output
Load
(opt.)
OK OK
Chassis GND is
made through the
DIN rail mounting
Single DC Supply
P1
P2
Front of
Switch
(connectors)
Back of
Switch
(DIN rail)
Redundant DC Power
Single DC Power
P2
P1
Dual DC Supplies
Power and Alarm Wiring For
SL/SLX-6ES Unmanaged Switches
-------------------------------------------------------
Single DC Supply
Front of
Switch
(connectors)
Back of
Switch
(DIN rail)
-
+
+
-
Redundant DC Power
Single DC Power
P2
P1
OK
Dual DC Supplies
Alarm
Output
Load
(opt.)
Chassis
GND
(panel)
OK
P1
P2
-
+
Alarm
Output
Load
(opt.)
Chassis
GND
(panel)
Power and Alarm Wiring for
SLX-10/16/18-Mx Managed Switches
Front of
Switch
(
connectors
)
Front of
Switch
(connectors)

Hach sc200 Specifications

General

Enclosure Rating	NEMA 4X/IP66
Operating Temperature	-20 to 60 °C (-4 to 140 °F)
Ambient Temperature	-20 to 60 °C (-4 to 140 °F)
Enclosure Material	Polycarbonate
Operating Humidity	0 to 95% non-condensing
Relay Outputs	Up to 4 SPDT relays
Storage Conditions	-40 to 70 °C (-40 to 158 °F)
Display	Graphical LCD
Inputs	2 digital sensor inputs
Outputs	4-20 mA
Power Supply	100 to 240 VAC, 50/60 Hz
Analog Outputs	2 or 4, 0/4-20 mA
Certifications	CE
Communication	Modbus RTU, HART
Dimensions	144 x 144 mm
Mounting	Panel mount
Output	4-20 mA
Power Requirements (Voltage)	100 to 240 VAC
Warranty	1 year
Weight	1.2 kg
