• The controller is shipped with two sets of slides appropriate for the
user’s controller model:
• One set of slides is already inserted into the operating panel
• The other set does not include a picture slide and is packaged
separately.
Printing Customized Slides Using Templates
• Slides can also be created by using Visio and Word stencils
designed for the user’s controller model.
• The resulting slides can be printed on film and cut to size.
Labeling Slides
• Slides can be labeled with a fine-tip permanent marker or
professional labeling tool.
Removing and Inserting Slides
• To access slides, move the rubber seal seated in back of the
operating panel.
Slides fit tightly into the operating panel slots to keep the
label over the correct key. Avoid use of excessive force
when removing or inserting slides in order not to damage
the slides.
Removing a Slide
• Slides have tabs to allow for easy removal.
1. Grasp the tab with fingers or flat-bladed long-nose pliers.
2. Pull gently and steadily until the slide slowly slips out.
Inserting a Slide
• Gently and steadily slip the slide into the slot.
CAUTION
7-2
