Ultima® X Series Gas Monitors
Ultima X Series Gas Monitors are well-suited to indoor and outdoor applications in virtually any industry
including oshore, reneries, chemical and petrochemical facilities, steel mills, water and wastewater plants,
mining, and general industry.
• Continuous hazardous gas monitoring using catalytic,
electrochemical, and infrared gas detection methods.
• DuraSource Technology provides extended infrared sensor life
• HART Field Communications Protocol option for improved asset
management
• Patented sensor disconnect-under-power allows sensor change-
out without declassifying a hazardous area
• Interchangeable smart sensors: pre-calibrated, installation-ready
sensor modules, eld-replaceable without tools
• New sensor type quick recognition and reconguration of alarm
and relay settings
• LCD conveniently alternates between sensor reading and gas
type, plus scrolling messaging for ongoing diagnostic checks
• Single-board design for ultimate reliability and serviceability
Acetylene IR- 0-2.5%
Ammonia- 0-50% LEL
Ammonia- 0-100 PPM
Ammonia- 0-1000 PPM
Arsine- 0-2 PPM
Bromine- 0-5 PPM
Carbon dioxide IR- 0-0.5%
Carbon dioxide IR- 0-2%
Carbon dioxide IR- 0-5%
Carbon monoxide- 0-100 PPM
Carbon monoxide- 0-500 PPM
Carbon monoxide- 0-1000 PPM
Chlorine- 0-5 PPM
Chlorine- 0-10 PPM
Chlorine- 0-20 PPM
Chlorine dioxide- 0-3 PPM
IR combustible gas -
Methane- 0-100% LEL
IR combustible gas -
Non-methane- 0-100% LEL
Combustible gas- 0-100%
LEL natural gas and H2
Combustible gas- 0-100%
LEL petroleum vapors
Combustible gas-
0-100% solvents
Diborane- 0-50 PPM
Ethylene oxide- 0-10 PPM
Fluorine- 0-5 PPM
Hydrogen uoride- 0-10 PPM
Hydrogen- 0-1000 PPM
Hydrogen chloride- 0-50 PPM
Hydrogen cyanide- 0-50 PPM
Hydrogen sulde- 0-10 PPM
Hydrogen sulde- 0-50 PPM
Hydrogen sulde- 0-100 PPM
Hydrogen sulde- 0-500 PPM
Nitric oxide- 0-100 PPM
Nitrogen dioxide- 0-10 PPM
Oxygen- 0-10% - compensated
Oxygen- 0-25% - compensated
Oxygen - CO2 tolerant- 0-25%
Oxygen - solvent tolerant-
0-25%
Phosphine- 0-2 PPM
Silane- 0-25 PPM
Sulfur dioxide- 0-25 PPM
Sulfur dioxide- 0-100 PPM
Gases
Ultima X Series installation and operation are both simple
and exible:
• Operates in diusion mode, with factory-calibrated sensors
ready to perform immediately after installation
• Oers HART upgrade of existing units via replacement PCBA
• Available for remote sensing applications, where installations
require sensor to be separated from electronics
• Can operate completely stand-alone with large LCD display,
optional quick-check LEDs, and 4 relay outputs (3 alarm and
1 fault), or connected with standard 4-20mA output to a control
system (PLC, DCS, etc)
• Adjustable full-scale range
• Easy installation with 2-piece, eld-wiring connectors
Calibration
As with all gas monitors, Ultima X Series Gas Monitors must be
calibrated periodically with the gas of interest to ensure proper
operation. The calibration process oers:
• Automatic adjustments
• Date stamping
• Calibration instructions displayed on monitor
• Selectable lockout of output signal during calibration
• Ability to calibrate at the installation location or remotely
without systems interruption
• Accessory calibrator, controller or pushbutton for
calibration initiation

Hach sc200 Specifications

General

Enclosure Rating	NEMA 4X/IP66
Operating Temperature	-20 to 60 °C (-4 to 140 °F)
Ambient Temperature	-20 to 60 °C (-4 to 140 °F)
Enclosure Material	Polycarbonate
Operating Humidity	0 to 95% non-condensing
Relay Outputs	Up to 4 SPDT relays
Storage Conditions	-40 to 70 °C (-40 to 158 °F)
Display	Graphical LCD
Inputs	2 digital sensor inputs
Outputs	4-20 mA
Power Supply	100 to 240 VAC, 50/60 Hz
Analog Outputs	2 or 4, 0/4-20 mA
Certifications	CE
Communication	Modbus RTU, HART
Dimensions	144 x 144 mm
Mounting	Panel mount
Output	4-20 mA
Power Requirements (Voltage)	100 to 240 VAC
Warranty	1 year
Weight	1.2 kg
