Ultima XE Gas Monitor –
Explosion-proof, stainless steel gas detector with display
The Ultima XE Gas Monitor oers:
• Explosion-proof 316 stainless steel.
• Multiple-entry mounting enclosure.
• Type 4X, IP66.
Ultima XA Gas Monitor –
Water- and corrosion-resistant, all-purpose,
polycarbonate gas detector with display
The Ultima XA Gas Monitor oers:
• NEMA 4X rating.
• Lightweight (only 1.5 lbs).
Ultima XIR Gas Monitor –
Explosion-proof, stainless steel, infrared gas detector with display
The Ultima XIR Gas Monitor oers:
• DuraSource Technology for improved IR sensor life.
• 316 stainless steel.
• Multiple-entry mounting enclosure.
• Fast response time.
• Operation based on dual-wavelength, heated-optics technology,
providing denitive compensation for temperature, humidity, and aging eects.
• IR technology for excellent long-term stability, eliminating the need
for frequent calibrations.
• Sintered disk-free design for optimum performance in harsh environments.
• No-gas calibration; only zero adjustment is required for full calibration.
• Type 4X, IP66 rating.
Ultima X Series Gas Monitors

Hach sc200 Specifications

General

Enclosure Rating	NEMA 4X/IP66
Operating Temperature	-20 to 60 °C (-4 to 140 °F)
Ambient Temperature	-20 to 60 °C (-4 to 140 °F)
Enclosure Material	Polycarbonate
Operating Humidity	0 to 95% non-condensing
Relay Outputs	Up to 4 SPDT relays
Storage Conditions	-40 to 70 °C (-40 to 158 °F)
Display	Graphical LCD
Inputs	2 digital sensor inputs
Outputs	4-20 mA
Power Supply	100 to 240 VAC, 50/60 Hz
Analog Outputs	2 or 4, 0/4-20 mA
Certifications	CE
Communication	Modbus RTU, HART
Dimensions	144 x 144 mm
Mounting	Panel mount
Output	4-20 mA
Power Requirements (Voltage)	100 to 240 VAC
Warranty	1 year
Weight	1.2 kg
