15 COMB-1S 100%LEL, 1% LEL, 55% LEL
16 COMB-1S-NL 100%LEL, 1% LEL, 25% LEL
17 COMB-1S-NL 100%LEL, 1% LEL, 40% LEL
18 COMB-1S-NL 100%LEL, 1% LEL, 55% LEL
275 CLO
2
3.0 PPM, 0.1 PPM, MSA 7CLH, 1.0 PPM
276 NH
3
100 PPM, 1 PPM, SENSORIC, 25 PPM
277 H
2
, 1000 PPM, 10 PPM, CTL 7HYT, 300 PPM
279 PHOSPHINE, 2.0 PPM, 0.1 PPM CTL 7SH, 0.5 PPM
280 ARSINE, 2.0 PPM, 0.1 PPM, CTL 7SH, 1.0 PPM
281 SILANE, 25 PPM, 1 PPM, CTL 7SH, 5 PPM
282 GERMANE, 3.0 PPM, 0.1 PPM, CTL 7SH, 2.5 PPM
283 DIBORANE, 50 PPM, 1 PPM, CTL 7SH, 15 PPM
284 FLUORINE, 5.0 PPM, 0.1 PPM, MSA 7CLH, 4.0 PPM
285 HF
286 BROMINE, 5.0 PPM, 0.1 PPM, MSA 7CLH, 2.5 PPM
287 ETO, 10.0 PPM, 0.1 PPM, 5 PPM
288 O
2
10.0%, 0.1% MSA 10019727, 5.0%
2IRIS
19 COMB-1S-100% LEL, 10% LEL, 31% LEL
20 COMB-1S-100% LEL, 1% LEL, 49% LEL
21 COMB-1S-100% LEL, 1% LEL, 68% LEL
22 Tankerguard
290 CLO
2
0.02 resolution
289 NH
4
1000
291 H
2
S 500
3 Custom IRIS 0-10000 PPM
101 IRIS - start
to IRIS - cont.
150 IRIS - finish
Table 3-15. Sensor Engineering Units
UNIT LABEL VALUE UNIT LABEL
0 None
1% LEL
2%
3 PPM
4 Future Expansion
3-11
