Hach sc200 - Mechanical Dimensions for SLX-16 MS-1; Mechanical Dimensions for SLX-18 MG-1

Sixnet Slim Line Switch Installation Guide Page 16 of 30
#6 screw
#8 screw
#10 screw
#12 screw
Panel mounting ears
accept up to a #12 screw
Direct to panel
mounting guide
Snaps to
standard
DIN Rail
EN50022
(35 mm)
Removable
Screw Block
Removable DIN
clip for direct
panel mounting
Panel mounting ears
accept up to
a #12 screw
2.76"
[7.01 cm]
2.76"
[7.01 cm]
0.35"
[0.88 cm]
0.39"
[0.99 cm]
5.52"
[14.02 cm]
2.15"
[5.46 cm]
2.15"
[5.46 cm]
Typical for SFP Xcvrs
0.50" [1.27 cm]
6.02"
[15.29 cm]
2.13"
[5.40 cm]
Mechanical Dimensions for SLX-16MS-1
2.88"
[7.31 cm]
#6 screw
#8 screw
#10 screw
#12 screw
Panel mounting ears
accept up to a #12 screw
Direct to panel
mounting guide
Snaps to
standard
DIN Rail
EN50022
(35 mm)
Removable
Screw Block
Removable DIN
clip for direct
panel mounting
Panel mounting ears
accept up to
a #12 screw
2.76"
[7.01 cm]
2.76"
[7.01 cm]
0.35"
[0.88 cm]
0.39"
[0.99 cm]
5.52"
[14.02 cm]
2.15"
[5.46 cm]
2.15"
[5.46 cm]
Typical for SFP Xcvrs
0.50" [1.27 cm]
6.02"
[15.29 cm]
Mechanical Dimensions for SLX-18MG-1
