User Interface and Navigation

Figure 17 Main Menu

4.2.1.3 Navigating the Menu Windows

To view a menu item, touch the menu item or use the UP and DOWN keys to highlight the

item. The menu item remains highlighted for approximately 4 seconds after it is selected.

To view the highlighted command, select the area to the left of the menu item or select the

ENTER button.

A “+” next to a menu command indicates there is a submenu. Touch the “+” to view the

submenu. An “i” next to a menu command indicates it is information only.

If a menu item is editable, highlight the item and touch the far-left part of the menu item

until it is highlighted and press

ENTER or double-tap the highlighted item. A keypad will be

displayed to change an entry (Figure 19 on page 25) or a list box will be displayed

(Figure 20 on page 26).

Messages are displayed in the message window (Figure 21 on page 26).

If an entry is incorrect, repeat the entry with the correct values. If the entry is outside the

working range, a correction to the entry is made automatically.

1. Display Area

33. BACK

34. FORWARD

35. ENTER–confirms the entry or selection.

36.

HOME–changes to the display of measured values. The pop-up toolbar cannot open from the menu window. To view the

Main Menu from this display, touch the Home button and then the bottom of the screen.

37.

UP–scrolls up

38.

DOWN–scrolls down

SENSOR STATUS

SENSOR SETUP

SYSTEM SETUP

TEST/MAINT
