Jumper Settings
• Tables C-2 through C-5 indicate how to set a specific jumper to
change the Controller functionality.
• To open the controller and access the jumpers, see FIGURES C-3
and C-4.
Incompatible jumper settings and wiring connections may
severely damage the controller.
Table C-2. JP1 Digital Inputs Type
TO USE AS JP1
npn (sink) A
pnp (source) B
Table C-3. JP2 Digital Inputs Voltage
TO USE AS JP2
12 VDC A
24 VDC B
Table C-4. JP5, JP6 Power Supply Voltage
TO USE AS JP5 JP6
10.2 to 15.6 VDC A A
15.6 to 28.8 VDC B B
Table C-5. JP3 Analog Input Type
TO USE AS JP3
Voltage input (default) A
Current input B
CAUTION
C-5
