Service
There are no internal adjustments to be made in the Ultima Controller.
For any service work, return to the unit to MSA:
MSA Instrument Repair and Service
1000 Cranberry Woods Drive
Cranberry Township, PA 16066-5207
or call toll-free: 1-800-MSA-INST.
Repair or alteration of these units, beyond the scope of these
maintenance instructions or by anyone other than authorized
MSA service personnel, could cause the products to fail to
perform as designed and persons who rely on these
products for their safety could sustain serious personal
injury or death.
Troubleshooting Guidelines
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION
CONTROLLER Dead batteries Replace batteries
OR
CALIBRATOR IS Dirty lens Clean the dark red lens on the front end
INOPERATIVE of the Controller or Calibrator
Too much Reduce the ambient light to the Ultima or
ambient light Ultima X Series Gas Monitor by creating
a light shield
"
WARNING
4-3

Hach sc200 Specifications

General

Enclosure Rating	NEMA 4X/IP66
Operating Temperature	-20 to 60 °C (-4 to 140 °F)
Ambient Temperature	-20 to 60 °C (-4 to 140 °F)
Enclosure Material	Polycarbonate
Operating Humidity	0 to 95% non-condensing
Relay Outputs	Up to 4 SPDT relays
Storage Conditions	-40 to 70 °C (-40 to 158 °F)
Display	Graphical LCD
Inputs	2 digital sensor inputs
Outputs	4-20 mA
Power Supply	100 to 240 VAC, 50/60 Hz
Analog Outputs	2 or 4, 0/4-20 mA
Certifications	CE
Communication	Modbus RTU, HART
Dimensions	144 x 144 mm
Mounting	Panel mount
Output	4-20 mA
Power Requirements (Voltage)	100 to 240 VAC
Warranty	1 year
Weight	1.2 kg
