INSTALLATION
Eaton
®
9130 UPS (700–3000 VA) User's Guide S 164201718 Rev 3 www.eaton.com/powerquality
27
Bottom EBM Cable Knockout
(underneath cover)
Top EBM Cable Knockout
EBM Cover Hook
Figure 12. Removing the EBM Front Cover
3. For the bottom (or only) EBM, remove the EBM cable knockout on
the top of the EBM front cover. See Figure 12 for the location of the
top EBM cable knockout.
4. If you are installing more than one EBM, for each additional EBM
remove the EBM cable knockout on the top and bottom of the EBM
front cover. See Figure 12 for the location of the EBM cable
knockouts.

Hach sc200 Specifications

General

Enclosure Rating	NEMA 4X/IP66
Operating Temperature	-20 to 60 °C (-4 to 140 °F)
Ambient Temperature	-20 to 60 °C (-4 to 140 °F)
Enclosure Material	Polycarbonate
Operating Humidity	0 to 95% non-condensing
Relay Outputs	Up to 4 SPDT relays
Storage Conditions	-40 to 70 °C (-40 to 158 °F)
Display	Graphical LCD
Inputs	2 digital sensor inputs
Outputs	4-20 mA
Power Supply	100 to 240 VAC, 50/60 Hz
Analog Outputs	2 or 4, 0/4-20 mA
Certifications	CE
Communication	Modbus RTU, HART
Dimensions	144 x 144 mm
Mounting	Panel mount
Output	4-20 mA
Power Requirements (Voltage)	100 to 240 VAC
Warranty	1 year
Weight	1.2 kg
