Appendix D,
Event Retrieval Tools
MSA provides access to a data retrieval tool called DataXport that is
available via the MSA support website. DataXport allows the user to
view alarm and fault events logged within the ModCon75 Controller.
DataXport saves the data logs in .ulp format. These data logs can be
opened using DataXport's companion application, DataXls, and the data
can then be exported to Excel files.
Via DataXport, you can:
View alarm and fault events logged within the controller.
Access PLCs and log events via a direct, network, Ethernet, or
modem connection.
To download this application tool, go to www.msanorthamerica.com
,
select “Fixed Gas Detection Instruments”, then “Software Downloads”.
The DataXport User’s Guide is located under “Fixed Gas Detection
Instruments”, “Controllers”, “ModCon 75 Controller” under the
Literature tab.
D-1
