F2-Add Unit Setpoints
Accesses the screen showing Current Setpoint values read from
the Ultima X3 unit (FIGURE 6-6).
Cursor flashes at the network ID#:
Enter the Unit ID for the Setpoints and alarm functions to be
modified and press enter
.
The current settings for the selected unit or ID appear.
To modify a setting, press the appropriate function key:
When all desired changes are made, press F6 to advance
to the next settings screen.
Repeat this procedure for other sensor option screens
(FIGURES 6-7 and 6-8).
If the user changes a sensor, the ModCon75 Controller will
retain the setpoints of the previous sensor. To upload new
setpoints, the user must populate the sensors through the
F1 menu option. Improper setpoints can result in exposure
to hazardous atmospheres.
(see "F1-Add Units to the Network" earlier in this chapter).
"
WARNING
Figure 6-6. Allows Users to Set
Enabled or Disabled Alarms
6-6
