Hach sc200 - Sensor Mounting Angle

19
Installation
• Install the sensor using the instructions supplied with the installation apparatus. See
Figure 12 for suggested mounting configurations.
• Sensor must be mounted at least 15º above horizontal. See Figure 13.
Figure 13 Sensor Mounting Angle
