9130 UPS (700–3000 VA) User's Guide S 164201718 Rev 3 www.eaton.com/powerquality
101
Chapter 8 Troubleshooting
The Eaton 9130 is designed for durable, automatic operation and also
alerts you whenever potential operating problems may occur. Usually
the alarms shown by the control panel do not mean that the output
power is affected. Instead, they are preventive alarms intended to alert
the user.
In general:
S Events are silent conditions that are recorded in the Event Log as
status information, such as “Clock Set Done.”
S Notices are announced by a beep every 5 seconds, recorded in the
Event Log, and displayed on the LCD. Examples are “UPS on
Battery” and “UPS on Bypass.”
S Alarms are announced by a beep every second, recorded in the Event
Log, displayed on the LCD, and the Alarm indicator illuminates.
Examples are “Output Overload” and “Heatsink Overtemperature.”
Use the following troubleshooting chart to determine the UPS alarm
condition.
Typical Alarms and Conditions
To check the UPS Status menu for a list of active alarms:
1. Press any button on the front panel display to activate the menu
options.
2. Press the
button until UPS STATUS displays.
3. Press the Enter button to display the list of active alarms.

Hach sc200 Specifications

General

Enclosure Rating	NEMA 4X/IP66
Operating Temperature	-20 to 60 °C (-4 to 140 °F)
Ambient Temperature	-20 to 60 °C (-4 to 140 °F)
Enclosure Material	Polycarbonate
Operating Humidity	0 to 95% non-condensing
Relay Outputs	Up to 4 SPDT relays
Storage Conditions	-40 to 70 °C (-40 to 158 °F)
Display	Graphical LCD
Inputs	2 digital sensor inputs
Outputs	4-20 mA
Power Supply	100 to 240 VAC, 50/60 Hz
Analog Outputs	2 or 4, 0/4-20 mA
Certifications	CE
Communication	Modbus RTU, HART
Dimensions	144 x 144 mm
Mounting	Panel mount
Output	4-20 mA
Power Requirements (Voltage)	100 to 240 VAC
Warranty	1 year
Weight	1.2 kg
