80459-641-01E Model 6 Motor Control Centers
10/2012 Section 9—iMCC
© 1999–2012 Schneider Electric All Rights Reserved
77
ENGLISH
Figure 108: Typical Cabling Scheme for Modbus
®
Two-Wire
Section 1 Section 2
Single tap trunk cable
(5000129-295)
ATV61/71 9-pin connector
cable (5000129-501)
6-tap trunk cable assembly
(5000129-83)
Female terminator
(5000129-187)
Device cable—general
cables (5000129-75)
20 in. (508 mm) extension (optional)
(5000129-76)
Male terminator
(5000129-186)
ATS48 cable
(5000129-75)
NOTE: Shield must be grounded
at one end only.
Orderable
Item
Part
Number
Cap for unused
male end or tap
3463512-1
Cap for unused
female end or tap
3463512-3
Mini female field
attachable
connector
5000129-287
Mini male field
attachable
connector
5000129-292
20 in. (508 mm)
trunk extension
5000129-76
25 in. (635 mm)
trunk extension
5000129-78
30 in. (762 mm)
trunk extension
5000129-79
35 in. (889 mm)
trunk extension
5000129-80
25 ft. (10.7 m)
cable extension
5000129-81

Hach sc200 Specifications

General

Enclosure Rating	NEMA 4X/IP66
Operating Temperature	-20 to 60 °C (-4 to 140 °F)
Ambient Temperature	-20 to 60 °C (-4 to 140 °F)
Enclosure Material	Polycarbonate
Operating Humidity	0 to 95% non-condensing
Relay Outputs	Up to 4 SPDT relays
Storage Conditions	-40 to 70 °C (-40 to 158 °F)
Display	Graphical LCD
Inputs	2 digital sensor inputs
Outputs	4-20 mA
Power Supply	100 to 240 VAC, 50/60 Hz
Analog Outputs	2 or 4, 0/4-20 mA
Certifications	CE
Communication	Modbus RTU, HART
Dimensions	144 x 144 mm
Mounting	Panel mount
Output	4-20 mA
Power Requirements (Voltage)	100 to 240 VAC
Warranty	1 year
Weight	1.2 kg
