Date of Last Cal Month,
Sensor 1 Base+239 1..12
Date of Last Cal Day
Sensor 1 Base+240 1..31
Date of Last Cal Year,
Sensor 2 Base+241 20XX
Date of Last Cal Month,
Sensor 2 Base+242 1..12
Date of Last Cal Day,
Sensor 2 Base+243 1..31
Date of Last Cal Year,
Sensor 3 Base+244 20XX
Date of Last Cal Month,
Sensor 3 Base+245 1..12
Date of Last Cal Day,
Sensor 3 Base+246 1..31
Drift counter- Sensor 1 Base+247 0..20
Drift counter- Sensor 2 Base+248 0..20
Drift counter- Sensor 3 Base+249 0..20
Internal Error Code -
Ultima X Base+250 For future implementation
Internal Error Code -
Sensor 1 Base+251 For future implementation
Internal Error Code - Sensor 2 Base+252 For future implementation
Internal Error Code - Sensor 3 Base+253 For future implementation
Information Flags 1 Base+254 See TABLE 3-16
Information Flags 2 Base+255 See TABLE 3-17
Information Flags 3 Base+256 See TABLE 3-18
Information Flags 4 Base+257 See TABLE 3-19
Alternate Gas Reading Sensor 1 Base+258 See TABLE 3-20
Alternate Gas Reading Sensor 2 Base+259 See TABLE 3-20
Alternate Gas Reading Sensor 3 Base+260 See TABLE 3-20
3-7

Hach sc200 Specifications

General

Enclosure Rating	NEMA 4X/IP66
Operating Temperature	-20 to 60 °C (-4 to 140 °F)
Ambient Temperature	-20 to 60 °C (-4 to 140 °F)
Enclosure Material	Polycarbonate
Operating Humidity	0 to 95% non-condensing
Relay Outputs	Up to 4 SPDT relays
Storage Conditions	-40 to 70 °C (-40 to 158 °F)
Display	Graphical LCD
Inputs	2 digital sensor inputs
Outputs	4-20 mA
Power Supply	100 to 240 VAC, 50/60 Hz
Analog Outputs	2 or 4, 0/4-20 mA
Certifications	CE
Communication	Modbus RTU, HART
Dimensions	144 x 144 mm
Mounting	Panel mount
Output	4-20 mA
Power Requirements (Voltage)	100 to 240 VAC
Warranty	1 year
Weight	1.2 kg
