Sixnet Slim Line Switch Installation Guide Page 23 of 30
Typical Fiber
Ports on
Unmanaged
Models
Typical Fiber
Ports on
Managed
Models
Typical Fiber
Ports on an
SL-8MG
Typical SC style
connector on a
SL-5ES-2/3SC
Typical ST style
connector on a
SL-5ES-2/3ST
Typical SC style
connector on a
SLX-5MS-4/5SC
Typical ST style
connector on a
SLX-5MS-4/5ST
Typical SC style
connector on a
SLX-8xS-
SLX-8MG with
no transceivers
installed
SLX-8MG with
four transceivers
installed
