Sixnet Slim Line Switch Installation Guide Page 28 of 30
Industrial Telephone Modem (SL-5MS-MDM Only)
Maximum data rates 56 Kbps
Compatibility V.90, V.34, V.32, V.32 bis, V.22, V.22 bis, V.21
Data compression V.42 bis
Error correction V.42 MNP or LAP
Ringer 0.3
Jacks 2 RJ11 (phone and line)
Command sets Standard AT and S register
Country compatibility World-wide (100+ countries)
Telecom ratings FCC Part 68; Industry Canada CS03-8; CTR21 (98/482/EC); ACA TS
001 and ACA TS 002
“PLC” Input and Output (SL-5MS-MDM Only)
PLC / Alarm output voltage Same as switch input power voltage
Maximum current output 0.5 Amp
PLC / Trigger input voltage 10-30 VDC
Typically current input 6.5 mA @ 24 VDC
“OK” Alarm Output (managed models only)
“OK” Output ON if P1 and P2 have power and switch software is running
Voltage Same as switch input voltage
Maximum current output 0.5 Amp
Power Input:
Power input Redundant Input Terminals
Input power (typical with
all ports active at 100
Mbps)
2.0 W (2-port converter with 1 fiber),
2.0 W (5-port unmanaged w/ 0 fiber),
3.0 W (5-port unmanaged w/ 1 fiber),
5.0 W (6-port unmanaged w/ 2 fiber),
4.0 W (8-port unmanaged w/ 0 fiber),
5.0 W (9-port unmanaged w/ 1 fiber),
8.0 W (8-port unmanaged w/ 3 fiber)
3.6 W (5-port managed w/o fiber),
4.8 W (5-port with phone modem),
5.6 W (5-port managed w/ 2 fiber),
4.3 W (8-port managed w/ 0 fiber),
6.3 W (8-port managed w/ 2 fiber),
9.0 W (8-port managed w/ 4 fiber),
12 W (8-port man. gigabit w/ 0 fiber)
15 W (8-port man. gigabit w/ 4 fiber),
5.0 W (10-port man. gigabit w/ 0 fiber),
7.0 W (10-port man. gigabit w/ 2 fiber),
7.0 W (16-port man. gigabit w/ 0 fiber),
8.0 W (18-port man. gigabit w/ 0 fiber),
10 W (18-port man. gigabit w/ 2 fiber)
Input voltage (all models) 10-30 VDC (continuous)
Reverse power protection Yes
Transient protection 15,000 watts peak
Spike protection 5,000 watts (10x for 10 uS)
