Sixnet Slim Line Switch Installation Guide Page 27 of 30
SC or ST Fiber Ports: (100BaseF multimode or singlemode)
100BaseF ports Up to 4
Fiber port mode Multimode (mm) or Singlemode (sm)
Fiber port connector Duplex SC or ST
Optimal fiber cable 50/125 or 62.5/125 μm for mm; 9/125 μm for sm
Center wavelength 1300 nm (other wavelengths available)
Multimode Links up to 4 km typ.; 1310 nm; use with 50 or 62.5/125 um fiber
> Transmitter power (dB): -21 min, -17 typ, -14 max
> Receiver sensitivity (dB): -34 typ, -31 max
Singlemode Links up to 20 km typical; 1310 nm; use with 9/125 um fiber
> Transmitter power (dB): -15 min, -11 typ, -8 max
> Receiver sensitivity (dB): -36 typ, -31 max
Singlemode long haul Links up to 40 km typical; 1310 nm; use with 9/125 um fiber
> Transmitter power (dB): -5 min, -3 typ, -0 max
> Receiver sensitivity (dB): -36 typ, -34 max
Nominal max. distance (full
duplex)
(see web for details)
4 km with multimode;
20 km with singlemode;
up to 120 km with long haul singlemode
Half and full duplex Full duplex on unmanaged models;
Software configurable on managed models
Ethernet compliance 100BaseF
Eye safety IEC 60825-1, Class 1; FDA 21 CFR 1040.10 and 1040.11
SFP Mini-Gbic SFP (pluggable) Ports: (many types available)
Note: On the Gigabit (MG) models these ports are pluggable and accept many different types of
pluggable SFP (Mini-Gbic) transceiver modules for Gigabit fiber connections.
Gigabit SFP ports Up to 4
Port types supported Gigabit fiber multimode, fiber singlemode, fiber long-haul
singlemode, fiber single-strand and more
Note: 100 Mbps fiber transceiver modules are also supported on these ports.
Fiber port connector LC typically for fiber (depends on module)
Optimal fiber cable Typical 50 or 62.5/125 μm for multimode (mm);
Typical 8 or 9/125 μm for singlemode (sm)
Fiber wavelength (typical) 850 nm for mm; 1310 nm for sm; 1550 for long haul sm
TX output power
RX input sensitivity
See fiber transceiver datasheet for details.
Max. distance (full duplex) Up to 80+ km with long haul singlemode modules
Half and full duplex Software Configurable
Ethernet compliance 1000BaseT and 1000BaseF (SX/LX/LH)
Eye safety IEC 60825-1, Class 1; FDA 21 CFR 1040.10 and 1040.11
Note: See SFP fiber optic transceiver datasheet for complete
specifications. Also, other fiber transceivers may be available for
special requirements such as longer distances, single strand (BiDi) or
other special applications. Contact Sixnet for details.
