HP 5900 series Command Reference

Predefined user roles
network-admin
network-operator
Parameters
vpn-instance vpn-instance-name: Specifies an MPLS L3VPN instance by its name, a case-sensitive string
of 1 to 31 characters. If you do not specify a VPN instance, the command displays the number of (S, G)
entries in the SA cache on the public network.
as-number: Specifies an AS number in the range of 1 to 4294967295. If you do not specify an AS
number, the command displays the number of (S, G) entries in the SA cache of all ASs.
Usage guidelines
You must execute the cache-sa-enable command before you execute this command. Otherwise, this
command does not give any output.
Examples
# Display the number of (S, G) entries in the SA cache on the public network.
<Sysname> display msdp sa-count
(S, G) entries statistics, counted by peer
Peer address SA count
10.10.10.10 5
(S, G) entries statistics, counted by AS
AS Source count Group count
? 3 3
5 (S, G) entries in total
Table 51 Command output
Field Descri
p
tion
(S, G) entries statistics, counted by peer Number of (S, G) entries on an MSDP peer basis.
Peer address Address of the MSDP peer that sent SA messages.
SA count Number of (S, G) entries from this MSDP peer.
(S, G) entries statistics, counted by AS Number of cached (S, G) entries on an AS basis.
AS
AS number. If the system could not obtain the AS number, this
field displays a question mark (?).
Source count Number of multicast sources from this AS.
Group count Number of multicast groups from this AS.
(S, G) entries in total Total number of (S, G) entries.
Related commands
cache-sa-enable
encap-data-enable
Use encap-data-enable to enable multicast data encapsulation in SA messages.
170

HP 5900 series Specifications

General

Ports	48x 10/100/1000BASE-T, 4x 10GE SFP+
Switching Capacity	1.28 Tbps
MAC Address Table Size	128K
Routing Protocols	RIP, OSPF, BGP, IS-IS
VLAN Support	4K VLANs
Dimensions	440 x 460 x 44 mm
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% (noncondensing)
